Types of Cabinet Hinges – Their Features & Finishes

Types of Cabinet Hinges

Types of Cabinet Hinges – Their Features & Finishes

Types of Cabinet Hinges

Did you know that there are numerous types of cabinet hinges having different looks, function, features and finishes? Here, we’ll briefly explain various types of cabinet hinges that come with different features, styles and finishes, which will help you to choose the right hinges when it’s time to buy brand new hinges for your kitchen, as well as, bathroom and laundry room cabinets.

Types of Cabinet Hinges

1. Pivot Hinge

Generally, you’ll find pivot hinges on home theatre system cabinets and lower cabinets. For inset doors on which you don’t want visible hinges, pivot hinges are the best. On the top and bottom of your cabinet door and frame, you’ll have to install these hinges.

Pivot Hinge

2. Wrap Around Hinge

Wrap around hinge’s face joins to the back of the door and the other face wraps around the face frame or cabinet frame, and then to the cabinet’s inside. If your cabinet doors are heavy, then wrap around hinges can provide adequate stability and support. The joints will be visible from cabinet’s outside, that’s why it’s important to ensure you choose a finish that gels with your cabinet’s design.

3. Barrel Hinge

Barrel hinges stay hidden so you won’t see them from the outside of the cabinet’s doors. Usually, people use barrel hinges for woodwork projects having lids, such as wooden storage boxes because they assist the lid to move up and down without changing its exterior look. Nonetheless, if you want to achieve a hinge-free look for your cabinet doors, then you can install barrel hinge.

4. Strap Hinge

A strap hinge mounts on the outside surface of your cabinets. They can be very short or long to fit the size and weight of your cabinet doors. Strap hinges are very versatile concerning what they can hold and their sleek looks.

Strap Hinge

5. Butt Hinge

One of the most commonly used types is the butt hinge; you’ll see it on diverse doors including cabinets. This hinge type has two sides that spread out; both sides connect to the joint, facilitating them to freely move. Typically, one side is connected to the cabinet’s frame and the other to the cabinet’s door. From cabinet’s outside, you’ll be able to see the joint, thus, it’s vital to select a finish that balances your cabinet’s look. A central pin or a ball joint is typically used by butt hinges for movement. They are made simple but are a dependable option for those looking for an effortless installation for their project, as well as, endures for many years.

Butt Hinges

6. Inset Hinge

Inset hinges come with the single narrow side that connects to the door’s frame whereas, the broader side connects to the door’s inside. The narrow part is visible from the cabinet’s outside, that’s why most of the inset hinges have an ornamental piece.

7. Full Overlay Hinge

You’ll need a full overlay hinge for cabinet doors covering the full face of the cabinet. These are available in different styles, but they usually go inside the cabinet, connecting to the door and the inside of a frame-less cabinet or the face frame.

8. Half Overlay Hinge

If you have a half overlay or partial overlay cabinets then you’ll need a half overlay hinge. Half overlay cabinets will have two doors that meet in the middle and share a tiny wall or partition. These hinges join to the inside of the doors and facilitate them to open near each other without striking each other. These hinges attach to the partition that’s shared by the two doors. Hinge’s size should be small to facilitate both of them to perfectly fit on the partition.

9. Flush Hinge

A flush hinge is very similar to a butt hinge, connecting to cabinet’s door and frame inside. Nonetheless, this hinge type can consume pretty less space in the door because when the door shuts, the small portion of the hinge closes into the large part, giving out an impression of one full piece. Similar to a butt joint, you can look at a flush hinge joint from cabinet’s outside, so choose your preferred finish.

Flush Hinges

10. Offset Hinge

Cabinet doors that pop out somewhat from the cabinet frame need an offset hinge type. As the two sides of the hinge don’t align, they assist the door to protrude from the frame. Offset hinge type connect to the outside of the cabinet frame and door, thus, they are accessible in a range of different styles and finishes, which lets you select one that perfectly matches with your cabinet design.

11. Frameless (Surface Mount) Hinge

Frameless (aka surface mount) hinges are easy to install compared to others because you won’t have to create a hole before installing them. As they mount on the inside of the cabinet frame and door, they facilitate the door to have enough space to swing out without striking the frame. You can align frameless hinges to make the right open and close for your cabinet doors.

12. Invisible Hinge

Invisible hinges are widely seen on home theatre system cabinets, but you can also use them on metal doors. They are comparatively smaller hinges and need very less space inside the door and frame where they join. These hinges won’t be easily seen even after opening your cabinet doors.

Invisible hinge

Features of Hinges

1. Heavy-Duty Hinge

You’ll normally see heavy-duty hinges in industrial than residential settings; they can hold more weight than ordinary ones. If your home’s cabinets doors are heavy due to their material or they’re oversized, then you can use heavy-duty hinges. Barrel and pivot hinges are commonly used heavy-duty hinge types that can hold a great deal of weight yet, facilitate effortless opening and closing.

2. Self-Close Hinge

Self-close hinges are known as spring-loaded hinges, but some don’t use springs instead, they use a hydraulic design. However, both designs facilitate your cabinet doors to close by itself using their weight. You’ll see this type of hinges on gym lockers and home theatre system cabinets, as well as, bathrooms and kitchen cabinets.

3. Soft-Close Hinge

When you attempt to close your cabinet door with a soft-close hinge, you’ll need to apply some pressure to push the door closed. When the door reaches a specific position, the hinge takes up facilitating it to slide into the closed position without a noise. Similar to a self-close hydraulic hinge, soft close hinge make use of hydraulics to produce a vacuum that closes the door. The design helps the door to close slowly, shielding itself from hitting as it settles. You can buy premium soft-close hinges of reputed Hettich brand.

Soft close hinge

4. Hidden Hinge

Hidden hinges aren’t visible from the cabinet’s outside. They are also known as concealed or invisible hinges and they can assist homeowners to obtain the ideal look for their cabinets. Hidden hinges join to the inside of the cabinet’s frame and the door, giving a feel that doors are floating on the face of the cabinet frame.

5. Demountable Hinge

Demountable hinges are beneficial for kitchen cabinets, as you can easily take them apart without removing any hardware and give a speedy wipe down to clean up grease particles and other dirt. They are available in both single and double demountable variants.

Demountable hinge

6. Ornamental Hinge

Hinges should possess excellent practicality and great looks. Many of the hinges can be seen from cabinet’s outside, so looks do matter. Thus, you’ll find many of the modern hinges with catchy designs so once they are installed, they look stunning from the cabinet’s outer part.

Various Hinge Finishes

If you want a seamless look for your bathroom and kitchen cabinets, then it’s vital to match your hinge’s finish to your cabinet’s look and feel. There are a variety of finishes available on the market to match your furniture. However, some common finishes include:

  • Chrome
  • Steel
  • Stainless steel
  • Brass
  • Copper
  • Nickel
  • Black
  • White

Where to Buy Cabinet Hinges Online

Well, you can buy high-quality hinges online of the choicest brands like Hafele and Hettich from Handles and More at attractive prices.
